Reference
Female thread
A14 200
A14 201
A14 202
Dimensions
Reference
A (inch)
B (inch)
C (inch)
D (inch)
E (inch)
A14 200
1.57
0.77
0.43
0.51
A14 201
1.97
0.98
0.51
0.67
A14 202
2.2
1.1
0.67
0.83
| Reference | Female thread | 3D |
|---|---|---|
| A14 200 | NPT1/8 | |
| A14 201 | NPT1/4 | |
| A14 202 | NPT3/8 |
Dimensions
| Reference | A inch | B inch | C inch | D inch |
|---|---|---|---|---|
| A14 200 | 1.57 | 0.77 | 0.43 | 0.51 |
| A14 201 | 1.97 | 0.98 | 0.51 | 0.67 |
| A14 202 | 2.2 | 1.1 | 0.67 | 0.83 |
