Polyamide (Nylon) Tubing in 1000 ft rolls
Color
Black
Ø ext. (in)
1/8" or 0.
Ø int. (in)
0.08 in
Max. output pressure
420.00
Radius of curve
0,375 inch
Temperature
-60.00°F to 199.00°F
Description
Reference
Color
Ø ext. (in)
Ø int. (in)
Max. output pressure
Radius of curve
Temperature
PABK I09181000
PABK I10531000
PABK I18141000
Dimensions
Reference
A (inch)
B (inch)
C (inch)
D (inch)
E (inch)
PABK I09181000
PABK I10531000
PABK I18141000
Description
| Reference | Color | Ø ext. (in) | Ø int. (in) | Max. output pressure | Radius of curve | Temperature | 3D |
|---|---|---|---|---|---|---|---|
| PABK I09181000 | Black | 1/8" or 0. | 0.08 in | 420.00 | 0,375 inch | -60.00°F to 199.00°F | |
| PABK I10531000 | Black | 5/32" or 0 | 0.106 in | 350.00 | 0,5 inch | -60.00°F to 199.00°F | |
| PABK I18141000 | Black | 1/4" or 0. | 0,180 in | 290.00 | 1,25 inch | -60.00°F to 199.00°F |
