1
318_IRC_061150
3D

Male coupler

ID passage
1/4"
Max. output pressure
174 psi
Temperature
5°F to 158°F

Plus de références

Reference
Net weight (kg)
Flow rate
BSPT male thread
Profile
IRC 061251
IRC 061252
IRC 061253

Dimensions

IRC_061150
Reference
A (inch)
B (inch)
C (inch)
D (inch)
E (inch)
IRC 061251
2.44
1.1
0.91
IRC 061252
2.44
1.1
0.91
IRC 061253
2.52
1.1
0.91
Reference Net weight (kg) Flow rate BSPT male thread Profile 3D
IRC 061251 0.078 Kg 28 CFM (P = 87 psi, ΔP = 8.7 psi) NPT1/4 INDUSTRIAL 3D
IRC 061252 0.084 Kg 28 CFM (P = 87 psi, ΔP = 8.7 psi) NPT3/8 INDUSTRIAL 3D
IRC 061253 0.090 Kg 28 CFM (P = 87 psi, ΔP = 8.7 psi) NPT1/2 INDUSTRIAL 3D

Dimensions

Reference A inch B inch C inch
IRC 061251 2.44 1.1 0.91
IRC 061252 2.44 1.1 0.91
IRC 061253 2.52 1.1 0.91
IRC_061150

⚠️ California Proposition 65 Warning

This product can expose you to chemicals known to the State of California to cause cancer and/or reproductive harm. For more information visit www.P65Warnings.ca.gov.
